Key Features:
Durable construction: Made from high-quality, chemical-resistant plastic
Versatile use: Suitable for both insecticide and air freshener aerosols
User-friendly operation: "Set and forget" functionality
Adjustable spray intervals: Choose between 7.5, 15, or 30-minute intervals
Manual on/off switch for convenience
Test switch: Allows for battery check, test spray, or manual spray on demand
Battery-operated: Uses 2 x D-cell alkaline batteries (not included)
2-Year Limited Warranty
Installation Instructions:
Mounting the Dispenser:
For optimal performance, install the dispenser 2.5 to 3 meters above floor level.
Hold the dispenser against the desired surface and mark the wall through the two mounting holes (M1).
Drill the marked points and insert the wall anchors.
Affix the unit to the wall using screws.
Ensure the unit is securely mounted.
Operating Instructions:
Insert 2 D-cell alkaline batteries into the battery compartment.
Select your preferred spray interval: 7.5, 15, or 30 minutes.
Before inserting the aerosol can, push the hammer mechanism to the up position.
Insert the aerosol refill between the metal brackets, ensuring the nozzle faces the front.
Use the on/off switch to power on the unit — the green LED will light up for 2 seconds.
Press the test switch to activate a test spray (always point away from the face).
When the refill is low, the green LED will begin blinking.
Switch the unit off, replace the can, and wait 60 seconds before turning it back on to reset the spray cycle.
Factory Setting: 15-minute spray interval, 24-hour operation.
Recommended Areas of Use:
Homes
Food preparation areas
Factories
Hotels
Offices
Retail shops
Washrooms and toilets
Precautions:
Do not use in the presence of individuals sensitive to pyrethroids.
If irritation or sensitivity occurs, seek medical attention.
Avoid excessive inhalation and contact with food.
Do not spray over plastic or highly polished surfaces (e.g., home appliances).
Weight: 0.73 kg
Dimensions: 11cm (L) x 24cm (W) x 9cm (H)
